SAE 100R17 Ultra Flexible Hydraulic Hose for Loader Hydraulic Systems with Tight Bend Radius
SAE 100R17 is an economical, lightweight textile-braid hose built for low-pressure applications where steel wire reinforcement is unnecessary. Its textile construction provides excellent flexibility, easy routing, and good resistance to oils and weather, making it a practical solution for non-critical circuits in agricultural, industrial, and automotive equipment. While not suitable for high-pressure or high-impulse conditions, it delivers dependable, cost-effective service in return lines, suction lines, pneumatic systems, and low-pressure fuel/oil lines. For simple fluid-handling needs, 100R17 is the go-to choice.
Key specs:
| Parameter | Specification |
|---|---|
| Reinforcement | One or two textile braids |
| Temperature | –40°C to +100°C |
| Working pressure | Up to 7 bar (100 psi) |
| Applications | Return lines, suction lines, air brakes, pneumatic systems |
Hydraulic Hose FeaturesEngineered for high pressure, extreme temperatures, and durability
-
Flexible, reliable, and built for long service life
-
Meets international standards (e.g., SAE, DIN, EN)
-
One source for all your hydraulic connection needs
-
OEM accepted
-
Customized hose accepted
-
Free hose sample available
Description
Inner Tube: Oil-Resistant Synthetic Rubber
-
Outer Cover: Abrasion & Ozone Resistant Synthetic Rubber. Note: Various Covers Available
Reinforcement: One Braid of High Tensile Steel Wire - Temperature: -40 ℃ ~ +100 ℃ / -40 ℃ ~ + 212 ℉
- Standard: SAE 100R17
- Option: Smooth Cover/ Wrapped Cover
Product Specification
| Serial | I.D.(inch) | I.D.(mm) | Braid (mm) | O.D.(mm) | Max. W.P.(Mpa) | Min. B.P.(Mpa) | Min. Bend Radius (mm) |
| PR17-03 | 3/16" | 5.0 | 8.8 | 10.4 | 21.0 | 84.0 | 45 |
| PR17-04 | 1/4" | 6.5 | 10.6 | 12.3 | 21.0 | 84.0 | 50 |
| PR17-05 | 5/16" | 8.1 | 12.1 | 14.1 | 21.0 | 84.0 | 55 |
| PR17-06 | 3/8" | 9.8 | 14.2 | 16.2 | 21.0 | 84.0 | 65 |
| PR17-08 | 1/2" | 12.8 | 18.5 | 20.4 | 21.0 | 84.0 | 90 |
| PR17-10 | 5/8" | 16.0 | 22.1 | 24.1 | 21.0 | 84.0 | 100 |
| PR17-12 | 3/4" | 19.0 | 26.3 | 28.4 | 21.0 | 84.0 | 120 |
| PR17-16 | 1" | 25.4 | 33.1 | 36.3 | 21.0 | 84.0 | 150 |
Product Details
— Various Hydraulic Hose —
About Hydraulic Hoses
Paishun is one of the top manufacturers of hydraulic rubber hoses in East China. We specialize in the production and marketing of these products.
Paishun's hydraulic hoses are particularly suitable for the following areas of application:
- Heavy equipment and earth-moving machinery at construction sites
-Mining and drilling
-Agricultural machines and equipment
-Working platforms, cranes, and lifting
-Pressure washer
