SAE 100R16 Hydraulic Hose with High Pressure
SAE 100R16 is a compact, high-performance hydraulic hose engineered for versatility and superior flexibility. Its two-wire braid construction offers approximately twice the flexibility of comparable SAE 100R2 hoses, resulting in a significantly smaller minimum bend radius that simplifies routing in tight spaces. While it provides working pressures comparable to standard two-wire braid hoses, its compact design makes it an excellent space-saving solution for demanding hydraulic circuits. With a 4:1 safety factor, broad fluid compatibility, and proven performance in off-road, agricultural, and industrial equipment, SAE 100R16 has become a widely adopted, multi-purpose standard that also meets ISO 11237 R16 and EN 857 2SC performance requirements.
Key specifications at a glance:
Hydraulic Hose FeaturesEngineered for high pressure, extreme temperatures, and durability
-
Flexible, reliable, and built for long service life
-
Meets international standards (e.g., SAE, DIN, EN)
-
One source for all your hydraulic connection needs
-
OEM accepted
-
Customized hose accepted
-
Free hose sample available
Description
Inner Tube: Oil-Resistant Synthetic Rubber
-
Outer Cover: Abrasion & Ozone Resistant Synthetic Rubber. Note: Various Covers Available
Reinforcement: Two Braids of High Tensile Steel Wire - Temperature: -40 ℃ ~ +100 ℃ / -40 ℃ ~ + 212 ℉
- Standard: SAE 100R16
- Option: Smooth Cover/ Wrapped Cover
Product Specification
| Serial | I.D.(inch) | I.D.(mm) | Braid (mm) | O.D.(mm) | Max. W.P.(Mpa) | Min. B.P.(Mpa) | Min. Bend Radius (mm) |
| PR16-04 | 1/4" | 6.5 | 12.2 | 14.2 | 35.0 | 140.0 | 50 |
| PR16-05 | 5/16" | 8.1 | 13.5 | 15.4 | 29.7 | 118.8 | 55 |
| PR16-06 | 3/8" | 9.8 | 15.7 | 17.6 | 28.0 | 112.0 | 65 |
| PR16-08 | 1/2" | 12.8 | 18.8 | 20.9 | 24.5 | 98.0 | 90 |
| PR16-10 | 5/8" | 16.0 | 22.4 | 24.4 | 19.2 | 76.8 | 100 |
| PR16-12 | 3/4" | 19.0 | 26.2 | 28.4 | 15.7 | 62.8 | 120 |
| PR16-16 | 1" | 25.4 | 33.6 | 36.2 | 14.0 | 56.0 | 150 |
| PR16-20 | 1-1/4: | 31.8 | 41.9 | 44.3 | 12.5 | 50.0 | 210 |
Product Details
— Various Hydraulic Hose —
About Hydraulic Hoses
Paishun is one of the top manufacturers of hydraulic rubber hoses in East China. We specialize in the production and marketing of these products.
Paishun's hydraulic hoses are particularly suitable for the following areas of application:
- Heavy equipment and earth-moving machinery at construction sites
-Mining and drilling
-Agricultural machines and equipment
-Working platforms, cranes, and lifting
-Pressure washer
