Chemical Resistance High Temperature Resistance Stainless Steel Braided Convoluted PTFE Hose Manufacturers | PASSIONHOSE

Material:

The corrugated bore PTFE tube is made of 100% polytetrafluoroethylene and does not contain any pigments or additives

Material Brand:

PTFE suppliers include FDA certified DuPont from USA, 3M from USA,Daikin from Japan, and top domestic brands

All Braided PTFE Hose can increase anti-static (including carbon) performance

Application:

With strong flexibility, it is suitable for applications that require smaller bending radius, pressure treatment, or compression resistance

All Braided PTFE Hose can increase anti-static (including carbon) performance

5.0
design customization

    oops...!

    no product data.

    Go to homepage
    Chemical Resistance High Temperature Resistance Stainless Steel Braided Convoluted PTFE Hose Manufacturers | PASSIONHOSE 5
    Product Features
    ---Why choose PTFE---
                                   Chemical Resistance High Temperature Resistance Stainless Steel Braided Convoluted PTFE Hose Manufacturers | PASSIONHOSE 6
    PTFE Features
    • ◪ Resistant to strong acid and alkali, resistant to various corrosive chemicals.

    • ◪ Anti-adhesive, anti-moisture and ultraviolet, non-toxic.

    • ◪ Excellent weather resistance, long service life, no brittle fracture and no aging.

    • ◪ With a very low friction coefficient. non-flammable.

    • ◪ With a very low evaporate transpiration rate, cold liquid is not volatile.

    • ◪ With excellent electrical characteristics.

    • ◪ Excellent mechanical properties, shock resistance and flexibility.




    Chemical Resistance High Temperature Resistance Stainless Steel Braided Convoluted PTFE Hose Manufacturers | PASSIONHOSE 7

    Product Description
    ---struction and specification---
    Description
    • Structure:

    • Inner tube: smooth PTFE(The imported F-205 of Japan Daikin PTFE)

    • Outer tube: stainless steel 304 wire braid (SS304 with diameter of 0.2mm and 0.25mm

    • Temperature:

    • Continuous temperature range: -65℃ to +260℃

    • Temporary temperature range: -70℃ to +300℃


    Chemical Resistance High Temperature Resistance Stainless Steel Braided Convoluted PTFE Hose Manufacturers | PASSIONHOSE 8
    Specification
    Part No.

    I.D.

    (inch)

    I.D.

     (mm)

    Tube Thickness (mm)

    O.D.

    (mm)

    W.P.

    (bar)

    B.P.

    (bar)

    Min.

    Bend Radius

    (mm)

    11/4"6.50.813.115040020
    25/16"8.00.6513.613036525
    33/8"10.00.6515.512535033
    41/2"13.00.8518.911033042
    55/8"16.0
    0.9023.48024550
    63/4"19.01.027.37021563
    71"25.01.033.05015079
    81-14''
    32.01.141.245140125
    91-1/2''38.0
    1.4547.943120145
    102''50.01.5
    63.035100180
    Chemical Resistance High Temperature Resistance Stainless Steel Braided Convoluted PTFE Hose Manufacturers | PASSIONHOSE 9
    Product Details
    ---various PTFE hose assemblies---
    Chemical Resistance High Temperature Resistance Stainless Steel Braided Convoluted PTFE Hose Manufacturers | PASSIONHOSE 10
    PTFE Hose Assembly

    45 deg. JIC female hose end in SS304

    Chemical Resistance High Temperature Resistance Stainless Steel Braided Convoluted PTFE Hose Manufacturers | PASSIONHOSE 11
    PTFE Hose Assembly

    straight JIC female hose end in SS304

    Chemical Resistance High Temperature Resistance Stainless Steel Braided Convoluted PTFE Hose Manufacturers | PASSIONHOSE 12
    PTFE Hose Assembly

    2 meters










    Chemical Resistance High Temperature Resistance Stainless Steel Braided Convoluted PTFE Hose Manufacturers | PASSIONHOSE 13
    PTFE Hose Assembly

    brass fittings with o-rings

    Chemical Resistance High Temperature Resistance Stainless Steel Braided Convoluted PTFE Hose Manufacturers | PASSIONHOSE 14
    PTFE Hose Assembly

    straight JIC female hose ends in carbon steel with zinc-nickel plated

    Chemical Resistance High Temperature Resistance Stainless Steel Braided Convoluted PTFE Hose Manufacturers | PASSIONHOSE 15
    PTFE Hose Assembly

    90 deg. elbow JIC female hos ends in carbon steel with zinc-nickel plated



    Chemical Resistance High Temperature Resistance Stainless Steel Braided Convoluted PTFE Hose Manufacturers | PASSIONHOSE 16

    Application
    ---high temperature, resist chemical---

    About PTFE Hose

    High temperature hydraulic, pneumatic and chemical delivery hoses for rubber, automotive, machine tools, shipbuilding, electromechanical, diesel, pressure control, paper and printing industries. For liquids, gases and highly corrosive media with alternating hot and cold heat, it has better performance and longevity than other hoses.


    Chemical Resistance High Temperature Resistance Stainless Steel Braided Convoluted PTFE Hose Manufacturers | PASSIONHOSE 17


    For Air System

    Convey high temperature and high-pressure air


    For Fuel Pump

    Covey high pressure and low pressure fuel
    Chemical Resistance High Temperature Resistance Stainless Steel Braided Convoluted PTFE Hose Manufacturers | PASSIONHOSE 18




    Hello, world!
    simple hero unit, a simple jumbotron-style con

    Chemical Resistance High Temperature Resistance Stainless Steel Braided Convoluted PTFE Hose Manufacturers | PASSIONHOSE 19




    For Oil Line

    Covey fuel for oil line in vehicle




    For Brake System

    Covey fuel for brake system in vehicle
