A hose manufacturer with over two decades of experience.

PASSIONHOSE | Latest hydraulic braided rubber hose company 1
PASSIONHOSE | Latest hydraulic braided rubber hose company 1

PASSIONHOSE | Latest hydraulic braided rubber hose company

The hydraulic braided rubber hose produced by is carefully selected materials, fine workmanship, and high quality. Compared with other similar products, it has a longer service life, better water-stop performance, and better shock absorption and buffer performance, and has a more competitive advantage in the market.
Inquiry

Set up years ago, PASSIONHOSE is a professional manufacturer and also a supplier with strong capabilities in production, design, and R&D. hydraulic braided rubber hose We have professional employees who have years of experience in the industry. It is them that provides high-quality services for customers all over the world. If you have any questions about our new product hydraulic braided rubber hose or want to know more about our company, feel free to contact us. Our professionals would love to help you at any time.hydraulic braided rubber hose Reasonable design, simple structure, excellent workmanship, high quality, long service life and wide application range.

PASSIONHOSE | Latest hydraulic braided rubber hose company 2
Product Features
---Why choose PTFE---
PASSIONHOSE | Latest hydraulic braided rubber hose company 3
PTFE Features
  • ◪ Resistant to strong acid and alkali, resistant to various corrosive chemicals.

  • ◪ Anti-adhesive, anti-moisture and ultraviolet, non-toxic.

  • ◪ Excellent weather resistance, long service life, no brittle fracture and no aging.

  • ◪ With a very low friction coefficient. non-flammable.

  • ◪ With a very low evaporate transpiration rate, cold liquid is not volatile.

  • ◪ With excellent electrical characteristics.

  • ◪ Excellent mechanical properties, shock resistance and flexibility.




PASSIONHOSE | Latest hydraulic braided rubber hose company 4

Product Description
---struction and specification---
Description
  • Structure:

  • Inner tube: corrugated PTFE(The imported F-205 of Japan Daikin PTFE)Outer tube: stainless steel 304 wire braid (SS304 with diameter of 0.2mm and 0.25mm

  • Temperature:

  • Continuous temperature range: -65℃ to +260℃

  • Temporary temperature range: -70℃ to +300℃


PASSIONHOSE | Latest hydraulic braided rubber hose company 5
Specification
SerialI.D.(inch)I.D.(mm)Thickness of tube (mm)O.D.(mm)W.P.(bar)B.P.(bar)Min. Bend Radius   (mm)
11/4"6.50.8013.115040020
25/16"8.00.6513.613036525
33/8"10.00.6515.512535033
41/2"13.00.8518.911033042
55/8"16.3
0.9023.48024550
63/4"19.01.0027.37021563
71"25.41.0033.05015079
81-1/4"32.01.1041.245140125
91-1/2"38.01.4547.943120145
102"50.01.5063.035100180
PASSIONHOSE | Latest hydraulic braided rubber hose company 6
Product Details
---various PTFE hose assemblies---
PASSIONHOSE | Latest hydraulic braided rubber hose company 7
PTFE Hose Assembly

45 deg. JIC female hose end in SS304

PASSIONHOSE | Latest hydraulic braided rubber hose company 8
PTFE Hose Assembly

straight JIC female hose end in SS304

PASSIONHOSE | Latest hydraulic braided rubber hose company 9
PTFE Hose Assembly

2 meters










PASSIONHOSE | Latest hydraulic braided rubber hose company 10
PTFE Hose Assembly

brass fittings with o-rings

PASSIONHOSE | Latest hydraulic braided rubber hose company 11
PTFE Hose Assembly

straight JIC female hose ends in carbon steel with zinc-nickel plated

PASSIONHOSE | Latest hydraulic braided rubber hose company 12
PTFE Hose Assembly

90 deg. elbow JIC female hos ends in carbon steel with zinc-nickel plated



PASSIONHOSE | Latest hydraulic braided rubber hose company 13

Application
---high temperature, resist chemical---

About our product

Stainless steel braided PTFE hoses are widely used in various industries for their unique properties and performance capabilities.

Here are some of the common applications:

1. Chemical industry: Stainless steel braided PTFE hose is used to transfer a wide range of chemicals, acids, and corrosive fluids, including solvents, fuels, and hydraulic fluids.

2. Food and beverage industry: These hoses are used in food and beverage processing plants to transfer food-grade fluids, such as milk, juice, beer, and wine, as well as cleaning solutions.

3. Pharmaceutical industry: Stainless steel braided PTFE hose is used in the pharmaceutical industry to transfer various chemicals and fluids, including solvents, acids, and cleaning solutions.

4. Automotive industry: These hoses are used in the automotive industry for fuel lines, oil lines, and brake lines due to their excellent resistance to high temperatures and corrosive fluids.

5. Aerospace industry: Stainless steel braided PTFE hose is used in the aerospace industry for various applications, including hydraulic lines, fuel lines, and cooling systems, due to their ability to withstand extreme temperatures and pressure conditions.


stainless steel braided PTFE hose is used in a wide range of applications where there is a need to transfer corrosive fluids, chemicals, and high-temperature fluids, especially in industries such as chemical, food and beverage, pharmaceutical, automotive, and aerospace.



PASSIONHOSE | Latest hydraulic braided rubber hose company 14


For Air System

Convey high temperature and high-pressure air


For Fuel Pump

Covey high pressure and low pressure fuel
PASSIONHOSE | Latest hydraulic braided rubber hose company 15




Hello, world!
simple hero unit, a simple jumbotron-style con

PASSIONHOSE | Latest hydraulic braided rubber hose company 16




For Oil Line

Covey fuel for oil line in vehicle




For Brake System

Covey fuel for brake system in vehicle
PASSIONHOSE | Latest hydraulic braided rubber hose company 17




Contact us
we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
