A hose manufacturer with over two decades of experience.

Paishun - 3/8 Medical PTFE Convoluted Tube With JIC Female Fittings PTFE Hose Assembly 1

Paishun - 3/8 Medical PTFE Convoluted Tube With JIC Female Fittings PTFE Hose Assembly 2

Paishun - 3/8 Medical PTFE Convoluted Tube With JIC Female Fittings PTFE Hose Assembly 3

Paishun - 3/8 Medical PTFE Convoluted Tube With JIC Female Fittings PTFE Hose Assembly 4

Paishun - 3/8 Medical PTFE Convoluted Tube With JIC Female Fittings PTFE Hose Assembly 5

Paishun - 3/8" Medical PTFE Convoluted Tube With JIC Female Fittings PTFE Hose Assembly

Name: Paishun - 3/8" Medical PTFE Convoluted Tube With JIC Female Fittings PTFE Hose Assembly
Uploaded: 2025-12-17T10:03:23+08:00
Description: The application of technology could play an important role in deciding the physical and chemical performance of 3/8" Medical PTFE Convoluted Tube With JIC Female Fittings.In the fields such as Plastic Tubes, the product is widely used and has a broad range of potential applications.

The application of technology could play an important role in deciding the physical and chemical performance of 3/8" Medical PTFE Convoluted Tube With JIC Female Fittings.In the fields such as Plastic Tubes, the product is widely used and has a broad range of potential applications.

Customization:

Customized logo (Min. Order: 1000 Meters),Graphic customization (Min. Order: 1000 Meters),Customized packaging (Min. Order: 1000 Meters)

shipping:

Support Sea freight · Land freight

Inquiry

Write a Review

Required Products

Total price discount:

BUY TOGETHER

Inquiry together

Hangzhou Paishun Rubber & Plastic Co., Ltd maintains stringent norms of quality to manufacture 3/8" Medical PTFE Convoluted Tube With JIC Female Fittings. It's designed out of the needs of our customers. Compared with the traditional ones, it better meets the market demands.

Place of Origin:	Zhejiang, China	Brand Name:	PAISHUN
Model Number:	R14-06C	Material:	PTFE, PTFE, SS304
Specification:	3/8" I.D.	Length:	2 meters
Thickness:	0.65mm	Processing Service:	extrusion and braid
Style:	ptfe convoluted hose	Size:	1/4" to 2"
Temperature:	-65C to +260C	Connection:	JIC female thread

Why Choose PTFE

Paishun - 3/8 Medical PTFE Convoluted Tube With JIC Female Fittings PTFE Hose Assembly 6

Character of PTFE

The PTFE hose material is made of Japanese Daikin.

The temperature range is -200C to +260C, melting point: 327C. It can't be injection molded and can be pressed and formed. The max. operating temperature is 280C.

PTFE has the following excellent properties due to its strong carbon-fluorine bond and high molecular wieght:

1. Excellent weather resistance, long service life, no brittle fracture and no aging.

2. Resistant to strong acid and alkali, resistant to various corrosive chemicals.

3. Anti-adhesive, anti-moisture and ultraviolet, non-toxic.

4. With a very low friction coefficuent. non-flammable.

5. With very low evaporate transpiration rate, cold liquid is not volatile.

6. With excellent electrical charateristics (does not change with frequency and temperature changes)

7. Excellent mechanical properties, shock resistance and flexibility.

Product Overview

Paishun - 3/8 Medical PTFE Convoluted Tube With JIC Female Fittings PTFE Hose Assembly 7

Inner tube: corrugated PTFE

Outer tube: stainless steel 304 wire braided Temperature range: -65℃ to +260℃

Advantage:

high temperature resistance, corrsion resistance, excellent flexibility and resistance to distortion

No	Specification	I.D.	O.D.	Thickness	W.P.	B.P	Min. Bending Radius
No	Specification			mm	mm	mm	bar	bar	mm
1	1/4	6.4	11.5	0.8	150	400	20
2	5/16	8	12.3	0.65	130	365	25
3	3/8	10	14.2	0.65	125	350	33
4	1/2	13	17.2	0.85	110	330	42
5	5/8	16	21.6	0.9	80	245	50
6	3/4	19	25.3	1	70	215	63
7	1	25	31	1	50	150	79
8	1 1/4	32	39	1.1	45	140	125
9	1 1/2	38	45	1.45	43	120	145
10	2	50	60	1.5	35	100	180

PTFE Hose Assembly

We can crimp the hose assembly in our factory.

Ferrule: 00TF0

Fitting: According to customers' request. Most of them use JIC Female thread.

Material 1: carbon steel with zinc plated

Material 2: carbon steel with nickel alloy plated

Material 3: SS304 / SS316

Paishun - 3/8 Medical PTFE Convoluted Tube With JIC Female Fittings PTFE Hose Assembly 10

Paishun - 3/8 Medical PTFE Convoluted Tube With JIC Female Fittings PTFE Hose Assembly 11

Application

High temperature hydraulic, pneumatic and chemical delivery hoses for rubber, automotive, machine tools, shipbuilding, electromechanical, diesel, pressure control, paper and printing industries. For liqids, gases and highly corrosive media with laternating hot and cold heat, it has better performance and longevity than other hoses.

-Flamethrower

-Air Compressor

Paishun - 3/8 Medical PTFE Convoluted Tube With JIC Female Fittings PTFE Hose Assembly 12

Paishun - 3/8 Medical PTFE Convoluted Tube With JIC Female Fittings PTFE Hose Assembly 13

Paishun - 3/8 Medical PTFE Convoluted Tube With JIC Female Fittings PTFE Hose Assembly 14

Packing&Shipping

Packing 1: PE bag with headcard for short hose assembly

Packing 2: by rolls with poly stripes

Paishun - 3/8 Medical PTFE Convoluted Tube With JIC Female Fittings PTFE Hose Assembly 15

Paishun - 3/8 Medical PTFE Convoluted Tube With JIC Female Fittings PTFE Hose Assembly 16

Paishun Can quote you EXW, FOB, CNF, CIF, DDU price based on the experienced shipment team.

Paishun - 3/8 Medical PTFE Convoluted Tube With JIC Female Fittings PTFE Hose Assembly 17

If you need the goods urgently, ship
by express is a good way. Paishun cooperates with over 5 express agents, who can get discounts from DHL, FedEx, UPS, TNT or some
special line to your door. Express cost is much lower than regular charges. Goods can be sent to your door dicrectly.

Paishun - 3/8 Medical PTFE Convoluted Tube With JIC Female Fittings PTFE Hose Assembly 18

If your goods is not small, and also want to get the goods quickly. A good way is to ship by air. Paishun can ship the goods from
air port in Hangzhou or Shanghai, etc.Goods can be sent to the nearest air port of your city.

Paishun - 3/8 Medical PTFE Convoluted Tube With JIC Female Fittings PTFE Hose Assembly 19

If you don't need the goods in a hurry, a good way is to ship by sea. Shipment cost is much lower. Paishun can ship from Ningbo Port, Shanghai Port, Lianyungang Port or other ports as your request. Goods can be sent to the nearest sea port of your city.
