Paishun - ID 1/4" 3/8" 1/2" EPDM High Temperature Rubber Air Water Hose Rubber Air Water Hose
We feature a broad range of hi-quality ID 1/4" 3/8" 1/2" EPDM High Temperature Rubber Air Water Hose for peolpe of all age group. ID 1/4" 3/8" 1/2" EPDM High Temperature Rubber Air Water Hose can help companies stand out in a fiercely competitive environment and become the industry leader in one fell swoop. Hangzhou Paishun Rubber & Plastic Co., Ltd will always adhere to the business philosophy of honesty, innovation, integrity to run our business. We believe that with the combined efforts of all our employees, we have enough skills and capabilities to overcome all obstacles and difficulties to make some achievements in the future.
| Place of Origin: | China | Brand Name: | Paishun |
| Model Number: | ID 1/4" 3/8" 1/2" | Processing Service: | Cutting |
| Material: | EPDM | Application: | high temperature air water |
| Color: | Red Blue | Size: | ID 6MM 10MM 13MM |
| Standard: | ISO 2398 | Working pressure: | 300 PSI |
| Length: | 100M | Surface: | Smooth surface |
| Reinforcement: | High tensile fiber | Temperature range: | -40 to 150 degc |
Heat Resistant Rubber Hose
This is a type of specially designed heat resistant hose. It is applied to circulating high temperature hot water, hot air and low - pressure steam in such demanding industrial place as chemical plants, refineries and wharves. It is characterized by aging and weather resistant and can be used all day long and st all weather.
As it is non-professional steam pipe, the pressure should be reduced while steam circulation. Please consult our engineer for details.
Structure:
1, Inner tube: EPDM rubber
2, Middle reinforcement: high-tensile polyester fiber braided.
2, Outer layer: EPDM rubber
Color: Red, Blue, Black, etc
Appearance:Smooth surface.
Temperature:-40 deg C to 150 deg C
Package: Standard exporting packing with transparent film and poly stripe.
Item code | Inner Diameter | Outer Diameter | Tolerance | Working Pressure | Burst Pressure | Length | Measurement | Weight | |||
inch | mm | mm | mm | bar | psi | bar | psi | m | cbm/roll | kg/m | |
HPH-05 | 3/16" | 4.8 | 12 | +/-0.3 | 20 | 300 | 60 | 900 | 100 | 0.025 | 0.16 |
HPH-06 | 1/4" | 6.4 | 13 | +/-0.3 | 20 | 300 | 60 | 900 | 100 | 0.03 | 0.21 |
HPH-08 | 5/16" | 7.9 | 16 | +/-0.4 | 20 | 300 | 60 | 900 | 100 | 0.04 | 0.25 |
HPH-10 | 3/8" | 9.5 | 18 | +/-0.5 | 20 | 300 | 60 | 900 | 100 | 0.05 | 0.31 |
HPH-13 | 1/2" | 12.7 | 22 | +/-0.6 | 20 | 300 | 60 | 900 | 50 | 0.04 | 0.43 |
HPH-16 | 5/8" | 15.9 | 26 | +/-0.7 | 20 | 300 | 60 | 900 | 50 | 0.055 | 0.58 |
HPH-19 | 3/4" | 19 | 30 | +/-0.8 | 20 | 300 | 60 | 900 | 50 | 0.07 | 0.73 |
HPH-25 | 1" | 25.4 | 37 | +/-0.9 | 20 | 300 | 60 | 900 | 50 | 0.1 | 0.98 |
