SAE 100R3 Two Fiber Braid Hydraulic Rubber Hose

SAE 100R3 is a versatile, textile-reinforced hydraulic hose built for general-purpose fluid-handling applications where steel wire reinforcement is unnecessary. Its double-braid fiber construction offers excellent flexibility and kink resistance, making it easy to route in tight spaces. While not suitable for high-pressure or high-impulse circuits, it provides a cost-effective and reliable solution for return/suction lines, fuel lines, and coolant systems in agricultural, industrial, and mobile equipment. With a 4:1 safety factor and good resistance to oils, ozone, and weather, it remains a dependable workhorse in non-critical hydraulic circuits.

Inquiry

Write a Review

Required Products

Total price discount:

BUY TOGETHER

Inquiry together

MEDIUM PRESSURE HYDRAULIC HOSE

SAE 100R3, R6, and EN 854 1TE/2TE/3TE are all textile-reinforced hydraulic hoses designed for low- to medium-pressure applications. They share: Oil-resistant synthetic rubber inner tube and cover Textile braid reinforcement (single or double layer) Operating temperature from –40°C to +100°C Common use in return lines, suction lines, and general-purpose hydraulic systems

Hydraulic Hose Features

Engineered for medium pressure, high pressure, extreme temperatures, and durability
Flexible, reliable, and built for long service life
Meets international standards (e.g., SAE, DIN, EN)
One source for all your hydraulic connection needs
OEM accepted
Customized hose accepted
Free hose sample available

Description

Inner Tube: Oil-Resistant Synthetic Rubber
Outer Cover: Abrasion & Ozone Resistant Synthetic Rubber. Note: Various Covers Available
Reinforcement: Two Braids of High Tensile Fiber
Temperature: -40 ℃ ~ +100 ℃ / -40 ℃ ~ + 212 ℉
Standard: SAE 100R3
Option: Smooth Cover/ Wrapped Cover

Product Specification

Serial	I.D.(inch)	I.D.(mm)	O.D.(mm)	Max. W.P.(Mpa)	Min. B.P.(Mpa)	Min. Bend Radius (mm)
PR3-03	3/16"	5.0	12.7	10.5	42.0	75
PR3-04	1/4"	6.5	14.3	8.7	34.8	75
PR3-05	5/16"	8.0	17.0	8.4	33.6	100
PR3-06	3/8"	9.8	19.0	7.8	31.2	100
PR3-08	1/2"	12.8	19.5	7.0	28.0	125
PR3-10	5/8"	16.0	23.7	6.1	24.4	140
PR3-12	3/4"	19.0	27.0	5.2	20.8	150
PR3-16	1"	25.4	31.6	3.9	15.6	205
PR3-20	1-1/4"	32.0	37.6	2.6	10.4	250

Product Details

— Various Hydraulic Hose —

About Hydraulic Hoses

Paishun is one of the top manufacturers of hydraulic rubber hoses in East China. We specialize in the production and marketing of these products.

Paishun's hydraulic hoses are particularly suitable for the following areas of application:

- Heavy equipment and earth-moving machinery at construction sites

-Mining and drilling

-Agricultural machines and equipment

-Working platforms, cranes, and lifting

-Pressure washer

Construction Machinery

With high impulse performance, PAISHUN hydraulic hose can be widely used on construction machinery such as excavators, bulldozers, earthmoves, etc.

Mining and Drilling

With the MSHA certificate andextraordinary anti-flame resistance performance, PAISHUN hydraulic hose can be used on Mining industry.

Agricultural Machinery

PAISHUN hydraulic hoses deliver flexibility, chemical resistance, and all-weather durability – ideal for tractors, harvesters, sprayers, and other agricultural machinery.
