SAE 100R12 Four Wire Spiral High Pressure Hydraulic Hose
SAE 100R12 is a heavy-duty, four-spiral-wire reinforced hydraulic hose for ultra-high-pressure applications. It exceeds the performance of standard two-wire braided hoses, offering superior strength and fatigue resistance.
Key specs:
-
Max working pressure: up to 4,000–5,000 psi (depending on size)
-
Min burst pressure: 4× the working pressure
-
Reinforcement: four layers of spiral steel wire
-
Tube: oil-resistant synthetic rubber
-
Cover: abrasion- and weather-resistant synthetic rubber
Typical uses:
Earthmoving machinery, forklifts, agricultural equipment, and high-impulse hydraulic circuits.
Bottom line: It's the go-to choice when you need reliable, long-lasting performance under extreme pressure and continuous pulsing.
Hydraulic Hose FeaturesEngineered for high pressure, extreme temperatures, and durability
-
Flexible, reliable, and built for long service life
-
Meets international standards (e.g., SAE, DIN, EN)
-
One source for all your hydraulic connection needs
-
OEM accepted
-
Customized hose accepted
-
Free hose sample available
Description
Inner Tube: Oil-Resistant Synthetic Rubber
-
Outer Cover: Abrasion & Ozone Resistant Synthetic Rubber. Note: Various Covers Available
Reinforcement: Four Spirals of High Tensile Steel Wire - Temperature: -40 ℃ ~ +100 ℃ / -40 ℃ ~ + 212 ℉
- Standard: SAE 100R12
- Option: Wrapped Cover
Product Specification
| Serial | I.D.(inch) | I.D.(mm) | Braid (mm) | O.D.(mm) | Max. W.P.(Mpa) | Min. B.P.(Mpa) | Min. Bend Radius (mm) |
| PR12-06 | 3/8" | 9.5 | 17.2 | 20.2 | 28.0 | 112.0 | 125 |
| PR12-08 | 1/2" | 12.7 | 20.2 | 23.8 | 28.0 | 112.0 | 180 |
| PR12-10 | 5/8" | 16.0 | 24.2 | 27.4 | 28.0 | 112.0 | 200 |
| PR12-12 | 3/4" | 19.0 | 28.1 | 30.7 | 28.0 | 112.0 | 240 |
| PR12-16 | 1" | 25.4 | 34.9 | 38.0 | 28.0 | 112.0 | 300 |
| PR12-20 | 1-1/4" | 31.8 | 44.0 | 47.0 | 21.0 | 84.0 | 420 |
| PR12-24 | 1-1/2" | 38.1 | 50.4 | 53.5 | 17.5 | 70.0 | 500 |
| PR12-32 | 2" | 50.8 | 63.6 | 66.7 | 17.5 | 70.0 | 640 |
Product Details
— Various Hydraulic Hose —
About Hydraulic Hoses
Paishun is one of the top manufacturers of hydraulic rubber hoses in East China. We specialize in the production and marketing of these products.
Paishun's hydraulic hoses are particularly suitable for the following areas of application:
- Heavy equipment and earth-moving machinery at construction sites
-Mining and drilling
-Agricultural machines and equipment
-Working platforms, cranes, and lifting
-Pressure washer
