Paishun - Flexibility EPDM Pipe Resistant Air Water Heat Resistance Rubber Hose Rubber Air Water Hose
Hangzhou Paishun Rubber & Plastic Co., Ltd always upholds the principle of'complementary advantages, mutual benefit and win-win', and has established long-term cooperative relations with many well-known domestic and foreign companies. Technological innovation promotes products to achieve an invincible position in fierce competition. Compared with the traditional ones, it better meets the market demands.
| Place of Origin: | Zhejiang, China | Brand Name: | PASSION |
| Model Number: | high temperature rubber hose | Processing Service: | Cutting |
| Raw material: | EPDM | Color: | black, red, blue, green etc |
| Temperature range: | -25 deg C to 150 deg C | ID: | 1/4" ( 6mm ) |
| Working pressure: | 300psi ( 20bar ) | Burst pressure: | 900psi ( 60bar ) |
| Surface: | Smooth | Reinforcement: | Strengthening weaving fiber |
| Length: | 50m or 100m per roll | Temperature: | -30 to 150 Deg C |
High temperature resistant WP 20 bar and BP 60 bar fiber braided flexible heat resistant rubber hose 6mm
Structure
1. Interior lining + Strengthen lining + Exterior lining.
2. Strengthen lining is strengthening weaving fiber.
3. Interior and exterior use special rubber formula, which endure high temperature.
Application
For the transportation of high temperature air, steam and hot water.
Product Imformation
Size: 1/4" ( 6mm )
Color: Black, red, blue, green, etc.
Temperature Range: -25C ~ +150C
Data sheet of product
|
I.D |
O.D |
W.P |
B.P |
MAX LENGTH |
|||
|
MM |
In |
MM |
Mpa |
Psi |
Mpa |
Psi |
M |
|
5 |
3/16 |
11.5 |
2 |
300 |
6 |
900 |
100 |
|
6 |
1/4 |
12.5 |
2 |
300 |
6 |
900 |
100 |
|
8 |
5/16 |
14.5 |
2 |
300 |
6 |
900 |
100 |
|
10 |
3/8 |
17 |
2 |
300 |
6 |
900 |
100 |
|
13 |
1/2 |
22 |
2 |
300 |
6 |
900 |
100 |
|
16 |
5/8 |
25.5 |
2 |
300 |
6 |
900 |
100 |
|
19 |
3/4 |
29.5 |
2 |
300 |
6 |
900 |
100 |
|
25 |
1 |
37.5 |
2 |
300 |
6 |
900 |
60 |
Packaging: Well packed by transparent OPP film or according to your specific requirement.
Shipping: We ship the goods by express, by air, by sea or according to your requirement.
Lead time: according to your quantity, generally speaking, 30 days 20' FCL.
1. We can provide matching hose connection.
2. We can provide free hose sample.
3. Hydraulic rubber hose is also served.
4. Other sizes can be customized.
5. We can print words on the hose according to your requirement.
6. We can package the goods according to your requirement.
7.OEM orders are also acceptable.
1. How many kinds of payment do you have and what' s your main one ?
We have more than three kinds of payment and the main one is 30% deposit and 70% against the
copy of B/L.
2. How many sizes can you provide ?
The size of our products is usually from 3/16 inch to 1 inch, but other sizes can also be customized
according to your requirement.
3. Can you send free sample ?
Yes, it's OK.
